- GEAX-dtc80
GEAX-dtc80
- Share
Year
2024
Price
Contact Us For Pricing
Manufacturer
Geax
Model
DTC80
Condition
New
| Base | ||
| Engine power | 97.4kW – 131hp | |
| Undercarriage length | 4.065 mm – 13.3 ft | |
| Width over tracks | 2.490 mm – 8.2 ft | |
| Mast | ||
| Forward inclination | >10° | |
| Backward inclination | >10° | |
| Lateral inclination | ±5.5° | |
| Mast vertical stroke | 2.250 mm – 7.4 ft | |
| Rotary | ||
| Nominal torque | 82 kNm – 60.480 lbf ft | |
| Drilling speed | 10 ÷ 35 rpm – spin off: 70 rpm | |
| Winches | ||
| Main winch line pull | 110 kN – 24.730 lbf | |
| Aux winch line pull | 37 kN – 8.320 lbf | |
| Crowd system | ||
| Pull down force | 140 kN – 31.480 lbf | |
| Extraction force | 170 kN – 38.220lbf | |
| Excavation | ||
| Max pile diameter | 1.500 mm – 60 in | |
| Max pile depth | 31 m – 101.70 ft | |
| Min working headroom | 7.840 mm – 25.4 ft | |
| Transport | ||
| Length | 10.500 mm – 34.5 ft | |
| Width | 2.490 mm – 8.2 ft | |
| Height | 3.150 mm – 10.3 ft | |
| Weight | 25.000 kg – 55.110 lb | |
